Mercury Safety Industry Group

1KG Powder Ext.

5A 34B C

Specifications

Cylinder Diameter：85 mm
Cylinder Height：270 mm
Weight Full：2.2 kg
Test Pressure：27 bar
Working Pressure：14 bar
Temperature Range：-30˚C to +60˚C

Technical Descriptions

Epoxy Painting
Sticker Label / Screen Printing
Various Brackets Available
CE Approved Cylinder and Valve
EN3 Approved Pressure Gauge

Packaging Info.

1 Piece / Box
115 x 90 x 345
Long x Wide x Height in millimeter
10 Piece / Box
475 x 250 x 355
Long x Wide x Height in millimeter

2KG Powder Ext.

13A 70B C

Specifications

Cylinder Diameter：110 mm
Cylinder Height：317 mm
Weight Full：3.8 kg
Test Pressure：27 bar
Working Pressure：14 bar
Temperature Range：-30˚C to +60˚C

Technical Descriptions

Epoxy Painting
Sticker Label / Screen Printing
Various Brackets Available
CE Approved Cylinder and Valve
EN3 Approved Pressure Gauge

Packaging Info.

1 Piece / Box
125 x 115 x 395
Long x Wide x Height in millimeter
6 Piece / Box
365 x 265 x 405
Long x Wide x Height in millimeter

3KG Powder Ext.

21A 89B C

Specifications

Cylinder Diameter：130 mm
Cylinder Height：348 mm
Weight Full：5.4 kg
Test Pressure：27 bar
Working Pressure：14 bar
Temperature Range：-30˚C to +60˚C

Technical Descriptions

Epoxy Painting
Sticker Label / Screen Printing
Various Brackets Available
CE Approved Cylinder and Valve
EN3 Approved Pressure Gauge

Packaging Info.

1 Piece / Box
155 x 150 x 465
Long x Wide x Height in millimeter
4 Piece / Box
325 x 315 x 475
Long x Wide x Height in millimeter

4KG Powder Ext.

21A 89B C

Specifications

Cylinder Diameter：140 mm
Cylinder Height：399 mm
Weight Full：6.7 kg
Test Pressure：27 bar
Working Pressure：14 bar
Temperature Range：-30˚C to +60˚C

Technical Descriptions

Epoxy Painting
Sticker Label / Screen Printing
Various Brackets Available
CE Approved Cylinder and Valve
EN3 Approved Pressure Gauge

Packaging Info.

1 Piece / Box
160 x 155 x 510
Long x Wide x Height in millimeter

6KG Powder Ext.

27A 144B C

Specifications

Cylinder Diameter：150 mm
Cylinder Height：444 mm
Weight Full：9.3 kg
Test Pressure：27 bar
Working Pressure：14 bar
Temperature Range：-30˚C to +60˚C

Technical Descriptions

Epoxy Painting
Sticker Label / Screen Printing
Various Brackets Available
CE Approved Cylinder and Valve
EN3 Approved Pressure Gauge

Packaging Info.

1 Piece / Box
170 x 165 x 555
Long x Wide x Height in millimeter

9KG Powder Ext.

34A 183B C

Specifications

Cylinder Diameter：184 mm
Cylinder Height：489 mm
Weight Full：13.5 kg
Test Pressure：27 bar
Working Pressure：14 bar
Temperature Range：-30˚C to +60˚C

Technical Descriptions

Epoxy Painting
Sticker Label / Screen Printing
Various Brackets Available
CE Approved Cylinder and Valve
EN3 Approved Pressure Gauge

Packaging Info.

1 Piece / Box
200 x 195 x 595
Long x Wide x Height in millimeter

12KG Powder Ext.

55A 255B C

Specifications

Cylinder Diameter：184 mm
Cylinder Height：581 mm
Weight Full：170 kg
Test Pressure：27 bar
Working Pressure：14 bar
Temperature Range：-30˚C to +60˚C

Technical Descriptions

Epoxy Painting
Sticker Label / Screen Printing
Various Brackets Available
CE Approved Cylinder and Valve
EN3 Approved Pressure Gauge

Packaging Info.

1 Piece / Box
200 x 195 x 700
Long x Wide x Height in millimeter

30KG Powder Ext.

A II B C

Specifications

Cylinder Diameter：300 mm
Cylinder Height：578 mm
Weight Full：51.0 kg
Test Pressure：27 bar
Working Pressure：14 bar
Temperature Range：-30˚C to +60˚C

Technical Descriptions

Epoxy Painting
Sticker Label / Screen Printing
Various Brackets Available
CE Approved Cylinder and Valve
EN3 Approved Pressure Gauge

Packaging Info.

1 Piece / Box
420 x 380 x 520
Long x Wide x Height in millimeter

50KG Powder Ext.

A IV B C

Specifications

Cylinder Diameter：300 mm
Cylinder Height：919 mm
Weight Full：83.0 kg
Test Pressure：27 bar
Working Pressure：14 bar
Temperature Range：-30˚C to +60˚C

Technical Descriptions

Epoxy Painting
Sticker Label / Screen Printing
Various Brackets Available
CE Approved Cylinder and Valve
EN3 Approved Pressure Gauge

Packaging Info.

1 Piece / Box
420 x 380 x 780
Long x Wide x Height in millimeter
